Neural Networks for 3D Medical Imaging

When working with a lot of medical imaging data, you have to deal with the 3D aspect of it.
So how do you build a deep learning solution for this type of data?
​
Here are 6 neural network architectures that you can use to train a deep learning model on 3D medical data:

3D U-Net:​
​
The U-Net architecture is a powerful model for medical image segmentation. The 3D U-Net extends the classic U-Net model to 3D segmentation. It consists of an encoding (downsampling) path and a decoding (upsampling) path.
​
The encoding path captures context in the input image, while the decoding path allows for precise localization. The 3D U-Net is very effective in handling the 3D nature of volumetric images.

You can check the code here.
​
​V-Net:​
​
The V-Net architecture is another 3D convolutional neural network designed for volumetric image segmentation. Similar to U-Net, V-Net has an encoder-decoder architecture, but it uses volumetric, full-resolution 3D convolutions, so it's more computationally expensive than U-Net.
​
You can find the code here.
​
​HighResNet:​
​
This architecture is designed to handle the challenges of segmentation of structures in 3D medical images. It uses a series of 3D convolutional layers with a residual connection. The model is trained end-to-end and can process an entire 3D image at once.
​
You can find the code here.
​
​EfficientNet3D:​
​
This is a 3D adaptation of the EfficientNet architecture, which has been successful in 2D image classification tasks. It is not as commonly used for 3D segmentation as U-Net or V-Net, but it may be worth considering if computational resources are limited, as it is designed to provide a good trade-off between computational cost and performance.
​
You can find the code here.
​
​Attention U-Net:​
​
This is a variation of U-Net that includes an attention mechanism, which allows the network to focus on certain parts of the image that are more relevant for the task at hand.
​
You can find the code here.
​
​DeepMedic:​
​
This is a 3D CNN that uses dual pathways, one with normal resolution and another with down-sampled input, in order to combine both local and larger contextual information.
​
You can find the code here.

​

MONAI is bringing some game changing tools to the market

This past week I joined an event held by Kitware Inc. about MONAI and how it can be used to do impressive work in Medical Imaging.
​
One of the tools that MONAI offers is generative modeling for medical imaging.
​
This tool is a package that allows you to train generative models such as diffusion models and VAEs (variational autoencoders).
​
The package has an easy to understand API for building and training these generative models.
​
One of the questions that I asked the presenter about this package was: how much data should we use to have acceptable results ?
​
The answer was: few hundreds !
​
This means that if you have let’s say 500 patients cases in 3D format you can already build a generative model that would perform relatively good!
​
Here are some of the features that MONAI Generative Models contains:

• Network architectures: Diffusion Model, Autoencoder-KL, VQ-VAE, Autoregressive transformers, (Multi-scale) Patch-GAN discriminator.
  ​
• Diffusion Model Noise Schedulers: DDPM, DDIM, and PNDM.
  ​
• Losses: Adversarial losses, Spectral losses, and Perceptual losses (for 2D and 3D data using LPIPS, RadImageNet, and 3DMedicalNet pre-trained models).
  ​
• Metrics: Multi-Scale Structural Similarity Index Measure (MS-SSIM) and Fréchet inception distance (FID).
  ​
• Diffusion Models, Latent Diffusion Models, and VQ-VAE + Transformer Inferers classes (compatible with MONAI style) containing methods to train, sample synthetic images, and obtain the likelihood of inputted data.
  ​
• MONAI-compatible trainer engine (based on Ignite) to train models with reconstruction and adversarial components.
